Casting Stokehole Laboratory instruments Stokehole Liquid iron management instrument JS-TG6 type |
|
JS-TG6 type Stokehole liquid iron quality management instrument that is what people say Stokehole Silicon-carbon analyzer, this instrument is our new generation of products plant, also known as casting Stokehole Laboratory instruments, Stokehole analyzer, high accuracy, easy to use and reliable . Cast iron Stokehole Rapid Cast iron thermal analysis technique based on tissue formation process of solidification temperature curve of the measured object by the computer on the solidification temperature curve into line analysis, to calculate the Liquid iron carbon equivalent (CE), the carbon content (C %), a silicon content (si%), ball rate (SG%), tensile strength (RM) and other indicators, Automatic calculated recarburiser, ferrosilicon, scrap put the amount of Liquid iron component is adjusted, Stokehole liquid iron quality management instrument is an effective way to achieve optimal control the quality of casting.
Instrument
Device
Regulation
Grid
|
Product Name
|
Stokehole liquid iron quality management instrument
|
type No.
|
JS-TG6
|
Hosts
|
Military grade Motherboard
|
Working humidity
|
0 ~ 50 ℃
|
Monitor
|
19 inches TFT color display
|
Operating temperature
|
<76%
|
Power supply
|
AC 220V 50Hz
|
Power consumption
|
200W
|
Outer shape
|
Desktop
|
Detection time
|
90 seconds
|
The main function
|
Measurement function
|
Liquid iron grades of carbon content in the silicon content of carbon equivalent degree of supercooling rate of the ball tensile strength
|
Setting Function
|
You can set the calibration curve 10, 10 kinds of target components, calibration curve and the target material linkage
|
Fill in the function
|
Based on the measurement results against the target component, Liquid iron weight, yield calculation additional amount
|
Record
|
By measuring the time sequence, it can record 5,000 measurements can reproduce process
|
Browsing
|
Visit the main trends in the distribution of the measured parameters, solidification temperature differential curve diagram
|
Output function
|
Optional measurement recording function Automatic output measurement data to U disk
|
Measurement accuracy
|
Project name
|
Measuring range
|
Measurement accuracy
|
Resolution
|
0.1 ℃ (0-1370 ℃)
|
0.1% FS
|
CE% value
|
2.30% -4.83%
|
± 0.10%
|
C% value
|
2.20% -4.30%
|
± 0.05%
|
Si% value
|
0.30% -3.80%
|
± 0.10%
|
SG% value
|
60% -95%
|
± 10.0%
|
RM value
|
HT100-HT350
|
Min
|
|
|
|
