MR2000 type known as Inverted Metallographic microscope Metallographic microscope, Metallographic analyzer
MR2000 type Inverted Metallographic microscope is widely used in schools, industrial and mining laboratory to identify and analyze the organizational structure of the metal and Alloy, after heat treatment of the material for research work in general microstructure, microscopic imaging clear, broad vision, true problem involving ergonomic features for a long time operation.
Magnification: 100X-1250X (depending on configuration)
Technical parameters:
|
Name
|
Specification
|
MR2000 Monocular
|
MR2000 eyes
|
MR2000 TRINOCULAR
|
|
Microscope body
|
|
√
|
√
|
√
|
|
Observation tube
|
Monocular tube
|
√
|
|
|
|
Binocular
|
|
√
|
|
|
Trinocular
|
|
|
√
|
|
Built-in digital head
|
|
|
Optional
|
|
Objective lens
|
Achromatic objective: 10X / 0.25 WD = 6.3mm
|
√
|
√
|
√
|
|
Achromatic objective lens: 40X / 0.65 WD = 0.7mm
|
√
|
√
|
√
|
|
Achromatic objective: 100X / 1.25 (oil) WD = 0.1mm
|
√
|
√
|
√
|
|
Achromatic objective lens: 50X / 0.75 WD = 2mm
|
Optional
|
Optional
|
Optional
|
|
Large field eyepiece
|
10X / diameter 18mm wide-field eyepiece
|
√
|
√
|
√
|
|
12.5X / diameter 14mm wide-field eyepiece
|
Optional
|
Optional
|
Optional
|
|
Filter
|
Green, blue, yellow, frosted glass sheet
|
√
|
√
|
√
|
|
Light source
|
12V20W halogen lamp, center, continuously adjustable brightness
|
√
|
√
|
√
|
|
Stage
|
Mesa Size: 180mm * 155mm; internet tablet two; small platform: drop type, round hole; mechanical mobile platform: moving range: 40mm * 30mm
|
Optional accessories:
|
● dedicated digital cameras
|
● Digital camera imaging device
|
● metallurgical fixed multiple printing system
|
|
● C type standard interface (or 0.5 times the interface)
|
● Metallographic image analysis software
|
● Standard micrometer card
|
|
● 10 times reticle eyepiece
|
|
|
|
|
|
|
